| Camera |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | Color: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | - Pan: 0° to 360°
- Tilt: 0° to 75°
- Rotate: 0° to 360°
|
| Lens |
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV | - 2.8 mm: horizontal FOV 111.1°, vertical FOV 57.6°, diagonal FOV 138.5°
- 4 mm: horizontal FOV 95.2°, vertical FOV 48.3°, diagonal FOV 117.4°
|
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | - 2.8 mm: 2.5 m to ∞
- 4 mm: 3.1 m to ∞
|
| DORI |
| DORI | - 2.8 mm: D: 61 m, O: 24 m, R: 12 m, I: 6 m
- 4 mm: D: 75 m, O: 30 m, R: 15 m, I: 7 m
|
| Illuminator |
| Supplement Light Type | White Light, IR |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Video |
| Main Stream | - 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
|
| Sub-Stream | - 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
|
| Third Stream | - 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- *The third stream is supported under certain settings
|
| Video Compression | - Main stream: H.265/H.264/H.264+/H.265+
- Sub-stream: H.265/H.264/MJPEG
- Third stream: H.265/H.264
- *Third stream is supported under certain settings
|
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream |
| Audio |
| Audio Type | Mono sound |
| Audio Bit Rate | - 64 Kbps (G.711ulaw/G.711alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 16-64 Kbps (AAC-LC)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
|
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/48 kHz |
| Environment Noise Filtering | Yes |
| Network |
| Protocols | - TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP
- SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
- WebSocket, WebSockets, SRTP, SFTP
|
| Simultaneous Live View | Up to 6 connections at the same time |
| API | ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| User/Host | - Up to 32 users
- 3 user levels: administrator, operator, and user
|
| Security | - Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5)
- Watermark, IP address filter, basic and digest authentication for HTTP/HTTPS
- WSSE and digest authentication for Open Network Video Interface
- RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3
- Host authentication (MAC address)
|
| Network Storage | NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
| Client | LTS Connect, NVMS V3, X-VMS |
| Web Browser | - Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+
- Localservice: Chrome 80+, Firefox 80+, Edge 89+
|
