Options and Related Products

Diameter:: Diameter: 0.0866"
Tool Size:: Tool Size: M2.2x0.45
Tap Limit:: Tap Limit: D3
Number of Flutes:: Number of Flutes: 2

Greenfield Threading, 330132, SPGP GT/VTD M2.2X0.45 SPGP D3 2FL GP Plug Spiral Point Tap

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

General
Brand Name	Greenfield Threading
Item #	330132
Style #	SPGP
Set	No
Dimensions
Diameter	0.0866"
Overall Lenght	1.7500"
Overall Lehgth (Metric)	44.45mm
Tool Size	M2.2x0.45
Thread Specifications
Thread Creation	Thread Cutting
Thread Form	Metric
Thread Length	0.4375"
Thread Length (Metric)	11.11mm
Thread Pitch	0.45
Thread Size	M2.2
Thread Tolerance	6H
Specification
Flute Type	Straight
Hand of Cut	Right
Material	HSS
Measurement System	Metric
Number of Flutes	2
Surface Condition	Bright
Tap Blank Construction	USCTI Table 302A
Tap Chamfer	Plug
Tap Construction	Standard
Tap Ground Threads	Yes
Tap Interrupted Thread	No
Tap Limit	D3
Tap Spiral Point	Yes
Tap Style	Spiral Point Tap
Tap Truncated Threads	No
Tap Type	Machine Tap
Shank Specification
Shank Configuration	Straight w/ Square
Shank End	Square
Shank Size	0.1410"
Shank Size (Metric)	3.58mm
Shank Square Length	0.1875"
Shank Square Length (Metric)	4.76mm
Shank Square Width	0.1100"
Shank Square Width (Metric)	2.79mm
Appliaction
Depth of Cut	2xD
Material Application	N: Non-ferrous Metal, P: Steel
Operation Type	Thru Hole

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

General
Brand Name	Greenfield Threading
Item #	330132
Style #	SPGP
Set	No
Dimensions
Diameter	0.0866"
Overall Lenght	1.7500"
Overall Lehgth (Metric)	44.45mm
Tool Size	M2.2x0.45
Thread Specifications
Thread Creation	Thread Cutting
Thread Form	Metric
Thread Length	0.4375"
Thread Length (Metric)	11.11mm
Thread Pitch	0.45
Thread Size	M2.2
Thread Tolerance	6H
Specification
Flute Type	Straight
Hand of Cut	Right
Material	HSS
Measurement System	Metric
Number of Flutes	2
Surface Condition	Bright
Tap Blank Construction	USCTI Table 302A
Tap Chamfer	Plug
Tap Construction	Standard
Tap Ground Threads	Yes
Tap Interrupted Thread	No
Tap Limit	D3
Tap Spiral Point	Yes
Tap Style	Spiral Point Tap
Tap Truncated Threads	No
Tap Type	Machine Tap
Shank Specification
Shank Configuration	Straight w/ Square
Shank End	Square
Shank Size	0.1410"
Shank Size (Metric)	3.58mm
Shank Square Length	0.1875"
Shank Square Length (Metric)	4.76mm
Shank Square Width	0.1100"
Shank Square Width (Metric)	2.79mm
Appliaction
Depth of Cut	2xD
Material Application	N: Non-ferrous Metal, P: Steel
Operation Type	Thru Hole

Note: Please read description carefully. Do not base your order on the picture presented.
