Flowline LI25-2001 DataLoop Intrinsically Safe Level Indicator

  • Brand Flowline
  • Part # LI25-2001
  • Model # DataLoop
Availability
Discontinued
Share:

Replacement

This product is discontinued, no longer available. Replacement part numbers:

Flowline, LI25-2001, DataLoop Intrinsically Safe Level Indicator, Intrinsically Safe Level Indicator

FM and CSA approved, the intrinsically safe loop powered level indicator displays engineering units connected in series with one 4-20 mA level transmitter. Select this panel mount indicator for use with intrinsically safe two-wire level transmitters. For field mount installation, add a single or double NEMA box.

Features:

  • Easy configuration via the push button display module
  • LCD main display with secondary unit and bar graph display
  • DIN enclosure with NEMA 4X faceplate and shallow case
  • Linear, square root and programmable exponent functions
  • Non-volatile memory with security password protection
  • Windowed NEMA box accessory for field installations


See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Authorized Distributor

Technical Details

Reviews
Display typeLCD, 5-digit
Display unitsEngineering
Display output-9999 to 99999
Display height0.6” (15mm)
Decimal pointFloating
BacklightLED, orange
ConfigurationPush button
MemoryNon-volatile
Sensor input(1) 4-20 mA transmitter
Loop power12-30 VDC
Voltage drop2.0 VDC w/o backlight 5.7 VDC w/ backlight
Process tempF: -22° to 149° C: -30° to 65°
Ambient tempF: -40° to 149° C: -40° to 65°
Enclosure type1/8 DIN, panel mount
Enclosure ratingNEMA 4X (IP65) faceplate
Enclosure mat'lPolycarbonate
ClassificationIntrinsically safe
ComplianceCE
ApprovalsFM, CSA: Class I, Div 1, 2, Groups A, B, C, D; Class II, Div 1, Groups E, F, G; Class II, Div 2, Groups G, G; Class III, Div 1; Class 1, Zone 0, Group IIC; T-code = T4
Product Details
Display typeLCD, 5-digit
Display unitsEngineering
Display output-9999 to 99999
Display height0.6” (15mm)
Decimal pointFloating
BacklightLED, orange
ConfigurationPush button
MemoryNon-volatile
Sensor input(1) 4-20 mA transmitter
Loop power12-30 VDC
Voltage drop2.0 VDC w/o backlight 5.7 VDC w/ backlight
Process tempF: -22° to 149° C: -30° to 65°
Ambient tempF: -40° to 149° C: -40° to 65°
Enclosure type1/8 DIN, panel mount
Enclosure ratingNEMA 4X (IP65) faceplate
Enclosure mat'lPolycarbonate
ClassificationIntrinsically safe
ComplianceCE
ApprovalsFM, CSA: Class I, Div 1, 2, Groups A, B, C, D; Class II, Div 1, Groups E, F, G; Class II, Div 2, Groups G, G; Class III, Div 1; Class 1, Zone 0, Group IIC; T-code = T4
