| Accuracy | ±1.5°C (2.7°F) for temperatures 50°C to 100°C (122°F to 212°F); up to ±3°C (±5.4°F) for -25°C to 50°C (-13°F to 122°F) and 100°C to 1030°C (212°F to 1886°F) |
| Detector Type | Focal plane array (FPA), uncooled microbolometer |
| Field of view (FOV) | 57° x 44° |
| IR Resolution | 160 x 120 pixels |
| Laser | Class 1 laser indicates the temperature measurement area; button-activated |
| Object Temperature Range | -25°C to 1030°C (-13°F to 1886°F) |
| Thermal Sensitivity/NETD | <70 mK |
| Built-in Illuminator LED | 100 lumens, 6500 K flashlight |
| FLIR Tools | Compatible |
| Certifications | CE, CB, RCM, IEC60825-1, FDA, UL, CEC, NRCan |
| Interface | USB 2.0, Bluetooth |
| Storage Media | eMMC 4 GB |
| USB | USB Type-C: data transfer/power |
| USB - Standard | USB 2.0 High Speed |
| Drop test | Designed for 2 m (6.6 ft) |
| EMC | EN 61000-6-3, EN 61000-6-2, FCC 47 CFR Part 15 Class B |
| Emissivity Correction | Yes: 4 preset levels with custom adjustment of 0.1–0.99 |
| Encapsulation | IP 54 (IEC60529) |
| Humidity (Operating and Storage) | 0-90% RH (0-37°C (32-98.6°F)), 0-65% RH (37-45°C (98.6-113°F)), 0-45% RH (45-55°C (113-131°F)) |
| Operating Temperature Range | -10°C to 45°C (14°F to 113°F) |
| Radio Spectrum | ETSI EN 300 328, FCC Part 15.249, RSS-247 Issue 2, EN 301 489-1:2011, EN 301 489-17:2009 |
| Safety | CE/CB/EN61010/UL |
| Shock | 25 g (IEC 60068-2-27) |
| Storage Temperature Range | -30°C to 55°C (-22°F to 131°F) |
| Tripod Mounting | 1/4 in.-20 on handle bottom |
| Vibration | 2 g (IEC 60068-2-6) |
| Built-in Digital Camera | Yes |
| Color Palettes | Iron, Rainbow, White hot, Black hot, Arctic, Lava |
| Detector Pitch | 12 µm |
| Digital Image Enhancement | Yes |
| Focus | Focus free |
| Gallery | Yes |
| Image Adjustment | Automatic |
| Image Frequency | 8.7 Hz |
| Image Modes | MSX(Multi Spectral Dynamic Imaging), Visual with temperature reading |
| Minimum Focus Distance | 0.3 m (0.98 ft) |
| Minimum Measurement Distance | 0.26 m (0.85 ft) |
| Spectral Range | 7.5 - 14 µm |
| Digital Camera Resolution/FOV | 2 MP (1600 x 1200 pixels), 71° x 56° FOV |
| Center spot | Yes |
| IR Temperature Resolution | 0.1°C (0.2°F) |
| IR Thermometer Measurement Acquisition | Continuous scanning |
| Languages | Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, simplified Chinese, Spanish, Swedish, traditional Chinese, Turkish |
| Set-up Commands | Local adaptation of units, language, date, and time formats, Screen brightness (high, medium, low), Gallery, deletion of images |
| Spot Meter | Center spot on/off |
| Camera size | 8.3" x 2.5" x 3.2" |
| Camera Weight Incl Battery | 0.13lbs |
| Cover Glass Material | Optical grade silicon |
| Display | 320 x 240 pixel, 2.4 in color LCD |
| Battery Operating Time | 5 hours continuous scanning, 4.5 hours with laser on |
| Battery Type | Rechargeable Li ion battery |
| Battery Voltage | 3.7 V |
| Charging System | Battery is charged inside the camera |
| Charging Temperature | 0°C to 45°C (32°F to 113°F) |
| Charging Time | 4 hours to 90%, 6 hours to 100% |
| Power Management | Adjustable: off, 5 min., 15 min., 30 min. |
| Battery Charge Life | 30 days minimum |
| Image Storage Capacity | 4 GB for storage of up to 50,000 pictures |
| Memory Type | Internal |
| Saved Image Format | JPEG |
