Voltage Output:: Voltage Output: 18V/3A

Constant Voltage/Current digital DC power supply with dual LCD. The 382202 is a DC power supply which provides an adjustable 0 to 30 Volts and 0 to 1 Amp output. Features dual backlit LCD display for current and voltage, short circuit and overload protection. Operates from 120VAC ±10%/60Hz power source. Banana plug outputs.

Features:

Constant voltage or current
Dual backlit LCD displays for voltage and current
Short circuit protection
Current limiting
High load/line regulation
Low noise/ripple
Banana plug output terminals

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Display	Dual LCD
Display Accuracy (V, A)	±(1.5%rdg); ±(2%rdg)
Voltage Output, DC	18.0 Volts
Current Output, DC	0 – 3.00 Amps
Ripple and Noise	<0.5mV/<3mA
Line Regulation	<0.01% + 3mV/<0.2% + 3mA
Load Regulation	<0.01% + 2mV/<0.2% + 3mA
Power	115V/230V; 50/60Hz
Dimensions (WxHxD)	9.4 x 4.25 x 6" (240 x 108 x 154mm)
Weight	6.6lbs. (3kg)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Display	Dual LCD
Display Accuracy (V, A)	±(1.5%rdg); ±(2%rdg)
Voltage Output, DC	18.0 Volts
Current Output, DC	0 – 3.00 Amps
Ripple and Noise	<0.5mV/<3mA
Line Regulation	<0.01% + 3mV/<0.2% + 3mA
Load Regulation	<0.01% + 2mV/<0.2% + 3mA
Power	115V/230V; 50/60Hz
Dimensions (WxHxD)	9.4 x 4.25 x 6" (240 x 108 x 154mm)
Weight	6.6lbs. (3kg)
