Series RDCV Diaphragm Valve, 1", remote coil, NPT connection, Cv factor of 23.

The Series RDCV Dust Collection Valves are ideal for use with the Series DCT1000 and Series DCT500 duct collection timer boards.The coupling connection allows for a quick and simple installation. Only the stub pipe and blow tube need to be cleaned and deburred before the valve is fit into position. The "T" Series DCV has female threaded connections. Both the "C" and "T" versions have a 90° angle between the inlet and outlet the most suitable configuration for pulse valve applications. The design offers not only ease of installation, but also minimal airflow restriction for an exceptional cleaning pulse. The valves are offered in both integrated and remote coil configurations.

Approvals

CE Approval

Report incorrect product information

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Notifications

Notifications: Item is non-returnable unless defective.
Please review our Return Policy.

Declaration

Declaration:: This product can be customized to your needs (voltage, ranges, sizes, additional documents, etc.). Please Contact Us or Add to Quote if any specific requirements are needed.

All sales are final

These are made-to-order items.
This product is not eligible for return or exchange unless defective.
The average lead-time is 1 or 2 weeks.

Technical Details

Optional Accessories

Reviews

Service	Compatible gases, filtered and oil free
Wetted Materials	Body: aluminum; Trim: 304 SS; Diaphragm and Seals: NBR; Diaphragm Disc: polyamide
Other Materials	Cover: aluminum; Body Bolts and Spring: 304 SS
Pressure Limits	Minimum of 4.4 psi (0.3 bar), maximum of 124.7 psi (8.6 bar)
Temperature Limits	Ambient: -4 to 140°F (-20 to 60°C); Operating: -4 to 185°F (-20 to 85°C)
Power Requirements	110 VAC, 220 VAC
Power Consumption	12 W, inrush: 17 VA
Mounting Orientation	Any position
Agency Approval	CE

Manufacturer List Price:	$69.50

Manufacturer List Price:

$69.50

Product Details

Service	Compatible gases, filtered and oil free
Wetted Materials	Body: aluminum; Trim: 304 SS; Diaphragm and Seals: NBR; Diaphragm Disc: polyamide
Other Materials	Cover: aluminum; Body Bolts and Spring: 304 SS
Pressure Limits	Minimum of 4.4 psi (0.3 bar), maximum of 124.7 psi (8.6 bar)
Temperature Limits	Ambient: -4 to 140°F (-20 to 60°C); Operating: -4 to 185°F (-20 to 85°C)
Power Requirements	110 VAC, 220 VAC
Power Consumption	12 W, inrush: 17 VA
Mounting Orientation	Any position
Agency Approval	CE

Manufacturer List Price:	$69.50

Manufacturer List Price:

$69.50
