Dwyer CDTC-5N000 Communicating Carbon Dioxide Transmitter 5000 PPM

Dwyer, CDTC-5N000, Communicating Carbon Dioxide Transmitter with Temperature Output, 5000 PPM Range and North American Housing

Features:

• Minimize inventory and save time by combining CO2 and temperature measurements into one transmitter
• Reduces the number of devices mounted in the space with integral temperature sensing
• Requires minimal maintenance with Automatic Baseline Correction (ABC) to account for sensor drift
• Field selectable Modbus® and BACnet communications reduces wiring
• Simplify installation with backplate electrical connection

Applications:

• Demand control ventilation in schools, office buildings, hospitals, and other indoor environments
• LEED® certification

The Series CDTC Communicating Carbon Dioxide Sensor combines the function of two room sensors into a single, compact housing. Parameters include carbon dioxide, temperature, and temperature set point with override. A 4-wire connection and daisy chaining together reduces installation cost. The RS-485 MAC address is set up using on-board DIP switches. Additional DIP switches are used to select Modbus® RTU or BACnet MS/TP and to limit access to the set up menu. The barometric pressure can be programmed to correct for altitude.
