Dixon Valve PBLSS1500 Stainless Panel Builder Gauge, 0 - 1500 PSI

Dixon Valve, PBLSS1500, Stainless Panel Builder Gauge, 0 - 1500 PSI, 2-1/2"

Applications

• All of the gauges supplied by Dixon are designed for long, reliable service under rugged conditions. Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement.

Use

• Suitable for corrosive environments
• Used in gaseous and liquid media

Specifications

• ASME B40.100 Grade A 2/1/2% full scale accuracy
• Figure interval: 300
• Minor gradient: 20

Features

• Fits industry standard 2.56" panel hole cutout

Construction

• 2-1/2" Face
• 1/4" lower back mount
• 316L stainless steel wetted parts materials
• Dial - white aluminum with black lettering; stop pin
• Pointer - black aluminum
• Glycerin filled
• Laminated safety glass window lens
