CDI 10002-I-DTT Digital Torque Tester, 3/8in Drive

  • Brand CDI
  • Part # 10002-I-DTT
  • Condition
    Brand New

Contact Us For Pricing

Availability
Contact Us
Check Availability
Quantity
Share:

CDI, 10002-I-DTT, Digital Torque Tester, 3/8in Drive, 100-1000 in.lb., 11.3-113 Nm

The Digital Torque Tester (DTT) is designed to be an affordable torque tester that can be mounted on a wall or used in a bench-top vise to allow the operator to conveniently test torque wrenches and torque screwdrivers. It Features an easy to use touch pad screen to capture peak torque values during a test in real time, and download stored torque data to a PC. All DTT torque testers are sold in a kit with the tester, carrying case and AC/DC power supply.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Authorized Dealer

Technical Details

Reviews
Female Drive3/8in
Range English100 - 1000 in.lb.
Range cNm, Nm11.3 - 113 Nm
Range, kgcm115 - 1152 cmkg
Accuracy+/- 0.50% 10% to 100% CW & CCW of indicated test value @ 25deg C
Units of MeasureNm, kgcm, ft.lb., in.lb., in.oz., kgm, cNm
Operation ModesTRACK, PEAK, FIRST PEAK
Operating Temperature10 to 32deg C (50 to 90deg F)
Storage Temperature-20 to 50deg C (-2 to 122deg F)
Humidity85% Relative Humidity @ 21deg C (70deg F)
Power SupplyIncluded 9-volt A/C D/C adapter. 6 AA batteries included
Data Storage/RecallMemory Capacity - 500 Records (Complete Check Mode Only.)
DimensionsW - 10in x H - 16in x D - 2.5in
Weight(Tester Only) - 10.7 lbs., (with Carrying Case) - 17.4 lbs.
Product Details
Female Drive3/8in
Range English100 - 1000 in.lb.
Range cNm, Nm11.3 - 113 Nm
Range, kgcm115 - 1152 cmkg
Accuracy+/- 0.50% 10% to 100% CW & CCW of indicated test value @ 25deg C
Units of MeasureNm, kgcm, ft.lb., in.lb., in.oz., kgm, cNm
Operation ModesTRACK, PEAK, FIRST PEAK
Operating Temperature10 to 32deg C (50 to 90deg F)
Storage Temperature-20 to 50deg C (-2 to 122deg F)
Humidity85% Relative Humidity @ 21deg C (70deg F)
Power SupplyIncluded 9-volt A/C D/C adapter. 6 AA batteries included
Data Storage/RecallMemory Capacity - 500 Records (Complete Check Mode Only.)
DimensionsW - 10in x H - 16in x D - 2.5in
Weight(Tester Only) - 10.7 lbs., (with Carrying Case) - 17.4 lbs.
Note

Note: Please read description carefully. Do not base your order on the picture presented.
