MultiPower Miniature Media Converter Fast Ethernet SFP

Features:

Bring fiber to the desktop more conveniently and at a lower cost than installing fiber NICs
Compact size; measures just 0.8"H x 1.8"W x 3.4"D.
Powered by a universal AC power supply or the optional rackmountable PowerTray.
Auto MDI/MDI-X means you never need to worry about what kind of cable to use.
Converters may also be powered from a USB port using the LHC021A USB power cable.
Autonegotiates for speed and duplex.
A DIP switch enables Link Fault Pass-Through to be turned on and off for better troubleshooting.

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

General
Connectors	(1) RJ-45, with autocross for MDI-II/MDI-X; (1) SFP
Dimensions	0.8"H x 1.8"W x 3.4"D (2 x 4.6 x 8.6 cm)
Humidity	5 to 95%, noncondensing
Indicators	LEDs: Per twisted-pair port: (1) TX Link/ACT, (1) FX Link/ACT; Per SFP port: (1) XMT, (1) RCV
Operating temperature	+32 to +122°F (+0° to +50°C);
Power	From the included external 100-240-VAC, 50-60-Hz adapter; Via USB Power Adapter Cable (LHC021A) connected to a computer's USB port; From the PowerTray with a 100-240 VAC, 50-60 Hz (LHC018A-AC-R2) or 7-50 VDC (LHC018A-DC-R2) power supply
Storage temperature	-13 to 158°F (-25 to +70°C);

General
Connectors	(1) RJ-45, with autocross for MDI-II/MDI-X; (1) SFP
Dimensions	0.8"H x 1.8"W x 3.4"D (2 x 4.6 x 8.6 cm)
Humidity	5 to 95%, noncondensing
Indicators	LEDs: Per twisted-pair port: (1) TX Link/ACT, (1) FX Link/ACT; Per SFP port: (1) XMT, (1) RCV
Operating temperature	+32 to +122°F (+0° to +50°C);
Power	From the included external 100-240-VAC, 50-60-Hz adapter; Via USB Power Adapter Cable (LHC021A) connected to a computer's USB port; From the PowerTray with a 100-240 VAC, 50-60 Hz (LHC018A-AC-R2) or 7-50 VDC (LHC018A-DC-R2) power supply
Storage temperature	-13 to 158°F (-25 to +70°C);

Note: Please read description carefully. Do not base your order on the picture presented.
