| Dimensions | 13.59 in H x 9.45 in W x 4.6 in D |
| Display Size | 2.12 x 2.81 in |
| Weight | 5.40 lb |
| Color | Blue |
| Application | Facility Identification, Safety Identification |
| Shipped With Battery | Yes |
| How Is the Battery Shipped | Shipped in a box, not installed |
| Battery mAh Rating | 1800 mAh |
| Battery Weight (metric) | 0.45 lb |
| Built-In Label Wizards | 66 Block, Arrow Tape, Breaker Box, DesiStrip, Face Plate, Flags, Patch Panel, Pipe Marker, Safety, Terminal Block, Vial, Wire Wrap |
| Connectivity Options | Bluetooth, USB, Wi-Fi |
| Cutter Type | Auto Cutter |
| Display Type | Color LCD Touch Screen |
| Keyboard Type | QWERTY |
| Memory | 200 MB (stores up to 100,000 labels) |
| Stand Alone Printing | Mobile device connected, PC connected & Stand-alone |
| Number of Symbols | 500+ |
| Plug Type | US |
| Power Supply Voltage | 110 - 245 V |
| Auto Shut-Off / Power Conserve | 5 minutes, User Configurable |
| Recharge Time | 3.5 hours |
| Special Characters Quantity | Depends on Regional Keypad |
| User Interface Type | Full QWERTY Keyboard |
| Battery Type | Rechargeable Lithium-ion Battery |
| Barcode Symbologies - 2D | Data Matrix, More through Brady Workstation, QR code |
| Barcode Symbologies - Linear | Code 128, Code 39, EAN-13, EAN-8, Interleaved 2 of 5, More through Brady WorkStation, More through software, UPC-A, UPC-E |
| Calibration Required? | Automated through Smart Cell |
| Color Printing Capability | Single Color |
| Font Sizes | 4 - 174 pt |
| Font Styles | Brady Alpine, Brady Fixed Width |
| Label Retention Feature | No |
| Maximum Labels per Day | 1000 |
| Maximum Print Speed | 3.0 in/s |
| Minimum Label Length | 0.236 in |
| Minimum Liner Width | 0.812 in |
| Print Resolution | 300 dpi |
| Print Technology | Thermal Transfer |
| On Screen Indicators | Battery Life, Bluetooth Status, Ribbon and label part number recognition, Ribbon Remaining, Supply Remaining, WiFi |
| Device Drop Test & Durability | Resistant to 4-foot drops, Sand & Dust |
| Compatible Media | BM-, BM7-, BM7C-, BMC-, M6-, M6C-, M7-, M7C- |
| Label Material Types | FreezerBondz Polyester, Heat-shrink Polyolefin, High-Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Nylon Cloth, Paper, Phosphorescent Polyester, Polyester, Polyester with Polyester Overlaminate, Polyethylene, Polyethylene Foam Laminate Polyester, Polyimide, Polyolefin, Polypropylene, Polyvinyl fluoride, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz Polyester, Static Dissipative Polyester, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth |
| Continuous & Die-Cut Materials Supported | Continuous and Die-cut |
| Custom Labels | Yes |
| Maximum Label/Tape Width | 2 in |
| Maximum Print Width | 1.921 in |
| Maximum Printed Label Length | 40 in |
| Maximum Liner Width | 2.25 in |
| Phones & Tablets Supported | Android devices with Android OS 6+, iPhone with iOS 10+ |
| Software Compatibility | Brady Workstation, Express Labels Mobile App |
| Languages | Bulgarian, Chinese (Traditional and Simplified), Croatian, Danish, Dutch, English (US), Estonian, Finnish, French (France), German, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Spanish (Spain), Swedish, Turkish |
